Temp. Range: Ambient – 200℃ (Controllable)
Control Accuracy: ±0.5℃
Temp. Uniformity: ±2.0℃( No load)
Temp. Rising Speed: RT – 150℃ (≧5℃/min, liner with load 40kg module)
Temp. overshoot: ≦2.0℃
Control Display Method:
PLC Touch screen + remote control, networking,
Cell phone APP alarm device, with USB interface, R485 interface can be connected to computer control.
Testing Room Dimension: W1000 X D1000 X H1000 mm
External Chamber Dimension: W1400 X D1300 X H1840 mm
Inner chamber Material: SUS304 Stainless Steel (Mirror finished)
External chamber Material: SECC Steel Plate, Powder Painted
Basement: With universal wheel
Observation Window:390 X 360mm (20mm Tempered Explosion Proof Glass)
Power Source: 380V 50HZ
Heating Power: About 12 KW
Safety Protection Device:
over-voltage, over-temperature, over-current protection.
protection for short circuits caused by incorrect operation of the operator and battery electrode, battery positive and negative connection, etc.
Safety Device: Smoke exhaust system, explosion-proof pressure relief port, tri-color light alarm.
