Test Space W x H x D (mm): 400x400x400
External Dimension W x H x D (mm): 700x570x810
Power Supply: AC 220V / 50HZ /4.0KW
Temp. Range: RT+10℃~200℃
Display Mode: Digital Display
Internal Material: 6.0mm thickness SUS 304# Stainless Steel
External Material: 1.5mm thickness SECC steel plate, powder painted coating
Bottom: Installed with universal wheel
Observation Window: Tempered glass with explosion – proof membrane
Timer: 4 digits display 0~9999（Hour, Minutes, Seconds changeable）
Vacuum Rate: 1.3Kpa（standard requires 11.6Kpa，vacuum gauge indication value -89.7Kpa）
Safety Devices: Remarks：as the inner chamber pressure is（101.325Kpa）, if wants the inner chamber pressure decreased to 11.6Kpa. Calculating according to atmosphere pressure of（101.325Kpa）, need to blow out (89.7Kpa) pressure of the inside chamber, then the inner chamber can reach low pressure environment of (11.6Kpa).
Pressure: 0~101Kpa（Controllable, display）
Pressure Fluctuation: ≤5%
