Internal Dimension: W2000 X D3000 X H2000mm
External Dimension: W2400 X D4500 X H2940mm
Temperature Range:-50℃ ~ +150℃ (Adjustable)
Humidity Range: 20%RH-98%RH
Temperature Fluctuation:±0.5℃
Humidity Fluctuation:±2.0％RH
Temperature Deviation:2.0℃
Humidity Deviation(A) >75%RH: ≤+2, -3%RH, (B) <75%RH: ≤±5%RH.
Heating Rate:≧5℃/min (From -40℃ up to +80℃, Non-linear load 800kg)
Cooling Rate:≧5℃/min (From -40℃ up to +80℃, Non-linear load 800kg)
Temperature overshoot:≤±2℃
Weight Approx: 5 Tons
Power Supply: AC 380V, 50HZ, 127KW
Noise:≤70dB (A-Level)
External Material:Galvanized sheet with high temperature electrostatic resin coating at both sides.
Internal Material:1.2 mm thickness SUS# 304 heat and cold resistant stainless steel with seal welding.
Controller:24-bit high accuracy 7 inch TFT true colors LCD touch screen.
Compressor:Semi-Hermetic Compressors BOCK / BITZER (Germany)
Cooling Type: Air cooling or water cooling (Optional)
Other Requiremen: Main-subsidiary type trolley for the specimen in and out of the test chamber.
Explosion-proof lighting system.
Explosion-proof pressure relief system.
Smoke exhaust system.
Automatic Water Supply System.
Fire extinguishing device; spray device; smoke alarm device.
