Core: ARM Cortex M0
Width: 2.4 mm
Height: 0.39 mm
Length: 2.66 mm
Technology: Si
Sensitivity: - 93 dBm
Unit Weight: 233.750 mg
Output Power: 0 dBm
Data RAM Size: 96 kB
Data RAM Type: SRAM
ADC Resolution: 10 bit
Data Bus Width: 32 bit
Interface Type: I2C, SPI, UART
Mounting Style: SMD/SMT
Maximum Data Rate: 1 Mbps
Operating Frequency: 2.4 GHz
Program Memory Size: 64 kB, 128 kB
Program Memory Type: OTP, ROM
Supply Voltage - Max: 3.6 V
Supply Voltage - Min: 900 mV
Number of ADC Channels: 4 Channel
Maximum Clock Frequency: 16 MHz
Supply Current Receiving: 3.7 mA
Supply Current Transmitting: 3.4 mA
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
