Fall Time: 38.6 ns
Rise Time: 9.6 ns
Technology: Si
Unit Weight: 6.750 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 53.7 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 12.5 W
Vgs - Gate-Source Voltage: - 12 V, + 12 V
Typical Turn-On Delay Time: 3.9 ns
Typical Turn-Off Delay Time: 30.8 ns
Id - Continuous Drain Current: 14.1 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 4.8 mOhms
Vds - Drain-Source Breakdown Voltage: 24 V
Vgs th - Gate-Source Threshold Voltage: 550 mV
