Width: 1.4 mm
Height: 1 mm
Length: 3.05 mm
Unit Weight: 8 mg
Configuration: Single
Mounting Style: SMD/SMT
Transistor Polarity: PNP
Pd - Power Dissipation: 625 mW
DC Current Gain hFE Max: 20000
Emitter- Base Voltage VEBO: 12 V
Collector- Base Voltage VCBO: 100 V
Continuous Collector Current: - 800 mA
Maximum DC Collector Current: 800 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
DC Collector/Base Gain hfe Min: 20000 at 100 mA at 5 V, 15000 at 1 A at 5 V, 5000 at 2 A at 5 V
Maximum Collector Cut-off Current: 10 nA
Collector- Emitter Voltage VCEO Max: 100 V
