Dimensions (W x H x D): 48 x 130 x 44 mm
Weight: 220 – 250 g
Ambient conditions
Temperature: -20 to +50 °C (-40 to +50 °C for max. 15 minutes)
Pressure: 700 to 1,300 mbar
Relative humidity: 10 to 95 % r.h.
Protection class: IP 67
Alarms
Visual: 360°
Audible: Multi-tone > 90 dB at 30 cm
Vibration
Operating times: ~ 12 h | >250 h without Ex Sensor
Charging time: < 4 h
Datalogger: Can be read out via Infrared > 1,000 hours with 6 gases and a recording interval of 1 value per minute
Pump operation: Maximum hose length 45 m; 148 ft.
Approvals
ATEX:
I M1 Ex da ia I Ma
II 1G Ex da ia IIC T4/T3 Ga
IECEx:
IECExEx da ia I Ma
Ex da ia IIC T4/T3 Ga
CSA (Canada & USA): Class I Div. 1 Group A, B, C, D, E, F, G T.-Code T4/T3
A/Ex da ia IIC T4/T3 /Ga
Measurement performance certificate:
EN 50104 | O2
EN 45544-1, EN 45544-2 | CO & H2S
EN 60079-29-1 | Methane to nonane, XXS H2 HC
CE mark: Electromagnetic Compatibility (Directive 2014/30/EU)
MED: Marine Equipment Directive (Directive 2014/90/EU)
EAC: PO Ex ia I Ma X
Consisting of: basic instrument with an integrated data logger, manufacturer‘s and calibration certificates. A functional instrument must include up to 4 sensors and a power supply unit (option).
Datasheet
Matching Sensors
Product | Order
number |
|
DrägerSensor
Dual IR Ex/CO2 ES | 6851880 | |
DrägerSensor
IR CO2 ES | 6851882 | |
DrägerSensor
IR Ex ES | 6851881 | |
DrägerSensor
XXS Amine | 6812545 | |
DrägerSensor
XXS CI2 | 6810890 | |
DrägerSensor
XXS CO / H2 compensated | 6811950 | |
DrägerSensor
XXS CO HC | 6812010 | |
DrägerSensor
XXS CO LC | 6813210 | |
DrägerSensor
XXS CO LC / H2S LC | 6813280 | |
DrägerSensor
XXS CO2 | 6810889 | |
DrägerSensor
XXS COCI2 | 6812005 | |
DrägerSensor
XXS H2 | 6812370 | |
DrägerSensor
XXS H2 HC | 6812025 | |
DrägerSensor
XXS H2S HC | 6812015 | |
DrägerSensor
XXS H2S LC | 6811525 | |
DrägerSensor
XXS HCN | 6810887 | |
DrägerSensor
XXS HCN PC | 6813165 | |
DrägerSensor
XXS NH3 | 6810888 | |
DrägerSensor
XXS NO | 6811545 | |
DrägerSensor
XXS NO2 | 6810884 | |
DrägerSensor
XXS NO2 LC | 6812600 | |
DrägerSensor
XXS O2 | 6810881 | |
DrägerSensor
XXS O2 / CO LC | 6813275 | |
DrägerSensor
XXS O2 / H2S LC | 6814137 | |
DrägerSensor
XXS O2 100 | 6812385 | |
DrägerSensor
XXS O2 PR | 6800530 | |
DrägerSensor
XXS Odorant | 6812535 | |
DrägerSensor
XXS OV | 6811530 | |
DrägerSensor
XXS OV-A | 6811535 | |
DrägerSensor
XXS Ozone | 6811540 | |
DrägerSensor
XXS PH3 | 6810886 | |
DrägerSensor
XXS PH3 HC | 6812020 | |
DrägerSensor
XXS SO2 | 6810885 |
