Integrated 35 – 2500MHz programmable local oscillator
IF range: 1 – 1000MHz
RF range: 25-2500MHz
Typical LO to RF isolation: 35dB
Typical LO to IF isolation: 25dB
Maximum RF power input: +17dBm
Phase noise at 4.4GHz: -82dBc (10KHz offset)
Low conversion loss: < 8dB typical
Return loss: >12 dB
Typical IP3: 20dBm
Input P1dB: +5dBm
LO Harmonic level: -30dBc typical (50-2500MHz)
Reference source: ±2.5PPM 10MHz TCXO
