Supply voltage: 380 ± 10% (220 ± 10%) (V)
Frenquency: 50/60 Hz
Max output current on busbars: 16A with 380V (13A with 220V)
Max output voltage on busbars: 7V
Output current measuring range (true rms): 20-16000A
Current measurement reduced error: 3%
Tripping time measuring range: 0.01-1000s
Time measurement reduced error: 1.5%
Temperature protection tripping: 96±5% (°С)
Max power consumption: 55kVA
Net weight: 56kg
Dimensions: 532x244x424mm
