Supply voltage: 380 ± 10% (220 ± 10%) (V)
Frenquency: 50/60 Hz
Max output current on busbars (AC): 20kA with 380V (13A with 220V)
Max output current on busbars (DC): 6kA
Max output voltage on busbars: 7V
Output current measuring range (true rms): 20-20000A
Current measurement reduced error: 3%
Tripping time measuring range: 0.01-1000s
Time measurement reduced error: 1.5%
Temperature protection tripping: 96±10% (°С)
Max power consumption: 55kVA
Current consumption of supply network: 140A
Net weight: 86kg
Dimensions: 1097x650x870mm
