Weight: 884.5 g
Accuracy: ± 1 %
Dial Dia: 5 in
Materials: 304 SS, Lens:Glass
Resolution: 2 °F
Stem Length: 2.5 in
Output Signal: Current
Current Output: 4 to 20 mA
Supply Voltage: 10 to 33 Vdc
Loop Resistance: 1045 Ω
Measurement Type: Temperature
Enclosure Ratings: IP66, NEMA Type 4X
Materials, Wetted: 304 Stainless Steel
Power Consumption: 38 mA
Supply Power Type: DC
Electrical Connection: 3/4 in NPT female Conduit with Screw Terminal block
Process Connection Size: 1/2 in
Process Connection Type: NPT Male
Process Temperature, Max: 200 °F
Process Temperature, Min: 0 °F
Operating Temperature, Max: 185 °F
Operating Temperature, Min: -58 °F
