Accuracy: ± 10 %
Valve Type: 6-Turn Needle Valve
Scale Length: 127 mm
Accuracy Note: ± 10% FS @ 70°F (21.1°C) and 14.7 psia (1 atm absolute)
Gas Flow, Max: 11 SCFM
Gas Flow, Min: 0.5 SCFM
Pressure Type: Gauge
Repeatability: ± 0.25%
Proof Pressure: Up to 200 psi
Turndown Ratio: 10:1
Liquid Flow, Max: 0 m³/s
Materials, Wetted: 316 Stainless Steel, Borosilicate, Fluoroelastomer, PTFE
Repeatability Note: ± 0.25% of scale reading
Media Compatibility: Air
Mounting Orientation: Vertical
Process Connection Size: 3/8 in
Process Connection Type: NPT Female
Operating Temperature, Max: 250 °F
Material Construction Option: Stainless Steel
