Direct access to our certified experts
Accuracy: ± 2 %, ± 5% with transitional flow
Materials: Aluminum, Polycarbonate
Valve Type: N/A
Scale Length: 65 mm
Accuracy Note: ± 2% FS @ 70°F (21.1°C) and 14.7 psia (1 atm absolute)
Gas Flow, Max: 17 ml/min
Pressure Type: Gauge
Repeatability: ± 0.25%
Tube Capacity: N/A
Proof Pressure: Up to 200 psi
Turndown Ratio: 10:1
Liquid Flow, Max: 0.28 ml/min
Materials, Wetted: 316 Stainless Steel, Aluminum, Borosilicate, Buna-N (NBR), PTFE
Repeatability Note: ± 0.25% of scale reading
Media Compatibility: Air, Water
Turndown Ratio Note: 10:1, 20:1 with combinations of two floats installed in meter
Mounting Orientation: Vertical
Process Connection Size: 1/8 in
Process Connection Type: NPT Female
Operating Temperature, Max: 250 °F
Material Construction Option: Stainless Steel
