Weight: 2.6 lb
Materials: Aluminum
Compliance: CE, FM
Switch Type: SPDT Micro
Bulk Density: 6 lb/ft³
Switch Rating: 5 A @ 250 Vac, 3 A @ 30 Vdc
Supply Voltage: 230 Vac
supply-voltage: 230 Vac
Pressure Limits: Up to 11.6 psi
Enclosure Ratings: IP66, NEMA Type 4
Materials, Wetted: Aluminum, Buna-N (NBR), Stainless Steel
Power Consumption: 4 VA
Supply Power Type: AC
Media Compatibility: Cement Powder, Dry Powder, Flour
Mounting Orientation: Side Mount, Top Mount
Electrical Connection: 3/4 in NPT female Conduit with Screw Terminal block
Enclosure Ratings Note: NEMA 4, IP66; Rated for Class II & III, Div. 1, Group E, F, G
Process Connection Size: 1 1/4 in
Process Connection Type: NPT Male
Process Temperature, Max: 176 °F
Process Temperature, Min: -13 °F
Operating Temperature, Max: 140 °F
Operating Temperature, Min: -4 °F
Permitted Mechanical Loading: Standard Shaft: 67 lbf max; Optional Extension: 22 lbf max
