Weight: 4.4 oz
Materials: Polycarbonate
Compliance: CE
Hysteresis: ± 0.8%
Sensor Type: RH: Capacitive Polymer humidity sensor, Temp: Diode temperature sensor
Output Signal: Current
Repeatability: ± 0.1%
Response Time: 8 s
Supply Voltage: 10 to 35 Vdc
RH Sensor Drift: <0.25% RH/year
Measurement Type: Temperature, Humidity
Relative Humidity: 0 to 100% RH
Supply Power Type: DC
Current Output Range: 4 to 20 mA
Mounting Orientation: Wall Mount
Voltage Output Range: N/A
Electrical Connection: Screw Terminal
Storage Temperature, Max: 176 °F
Storage Temperature, Min: -40 °F
Operating Temperature, Max: 140 °F
Operating Temperature, Min: -40 °F
Relative Humidity Accuracy: ± 2% RH
Solid State Band Gap Temperature Accuracy: ± 0.9°F @ 77°F
Solid State Band Gap Temperature Input Range: -40 to 140°F
