Weight: 3 lb
K-Factor: 0.001 to 999999.999
Materials: Aluminum, Polycarbonate
Input Note: 5 V pulse or contact closure; 1 to 15 pulses/s
Wire Gauge: 22 AWG
Display Note: Rate: 8 digits, 1/2 ̋ H LCD; Total: 8 digits, 5/16 ̋ character height
Display Type: LCD
Output Detail: Current sinking square wave pulse: Scaled pulse output (0.1 s duration 6.1 Hz max. or high alarm output or low alarm output), sensor pass-through pulse output (un-scaled); Pulse output range: 0.1 to 9999999.9 units/pulse; Analog: 4 to 20 mA, 24 to 30 VDC
Output Signal: Current, DC Pulse
Supply Voltage: 7 to 30 Vdc
Number of Digits: 8
Enclosure Ratings: IP67, NEMA Type 4X
Supply Power Note: 7 to 30 VDC @ 4 mA (4 to 20 mA when loop-powered)
Supply Power Type: DC
Input Control Signal: 5 V Pulse
Mounting Orientation: Wall Mount
Electrical Connection: Cable Gland with Screw Terminal block
Flow Alarm Output Range: 0.1 to 99999.99
Process Temperature, Max: 131 °F
Process Temperature, Min: -32 °F
Operating Temperature, Max: 158 °F
Operating Temperature, Min: -40 °F
