Weight: 2.2 lb
Accuracy: ± 0.25 %
Mounting: Suspended in Tank Below Level Being Measured
Compliance: CE, cULus, UKCA
Protection: Lightning and Surge Protection
Cable Length: 40 ft
Output Detail: 4 to 20 mA DC, 2-wire
Output Signal: Current
Pressure, Max: 10 psi
Response Time: 50 ms
Supply Voltage: 10 to 28 Vdc
Thermal Effect: ± 0.02% FS/°F
Loop Resistance: 900 Ω at 30 Vdc max
Electrical Output: 4 to 20 mA
Materials, Wetted: Fluoroelastomer, Polyether, Polyurethane, PVC, Stainless Steel
Supply Power Type: DC
Media Compatibility: Consult Factory
Electrical Connection: Pigtail Leads
Operating Temperature, Max: 176 °F
Operating Temperature, Min: -4 °F
Compensated Temperature, Max: 176 °F
Compensated Temperature, Min: 0 °F
Material Construction Option: Polyether Polyurethane cable jacket, Hazardous Location rated
material-construction-option: Polyether Polyurethane cable jacket, Hazardous Location rated
