DYS DWA – 2000A-D.O Analyzer and control DO - 2 points SET

ManufacturerDYS(View more products from this manufacturer)

ModelDWA- 2000A-D.O

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Function / Features

- Certificate : Certificate of Patent
Certificate of CE
- Relay Contact output (3 contacts)
High, Low Alarm & Cleaning Contact
- Simple Operation by 4 Keypad Button
- High brightness 7-segment display
- Isolated(4~20, 0~20, 0~24 mA DC) Output Transmission
- Automatic Cleaning Control(Air jet, Water jet) Function
- panel mounting (DIN 96 size)
- Microprocessor-based Digital Program Controller
- Low-Cost for user satisfaction

Specifications

Code No. : 413120001DO
Model : DWA-2000A-DO
Channel : Single channel
Range : 0 to 20 mg/L(Resolution: 0.01)
Meas. Method : polarograph
Power : AC 110/220V, 50/60Hz, 3VA
Accuracy : ± 1% of F.S
Repetition & Reappearance : ± 1% of F.S
Response time : 120 sec(90% saturation)
Analog output : 4~20mA DC(STD.)
Relay output : High, Low & Cleaning Contact
Display : measuring value(7-segment), Temp.
Humidity : max. 90%(non-condensing)
IP Rating : IP54
Size : 96(W)x96(H)x125(D)
Installation : Panel mounting(DIN96 Size)

OPTION:

	D.O ELECTRODE		PRICES (USD)
1	Electrodes ONLINE FOR TREATMENT, BODY BY PPS Model D34 Manufacturer: DYS - Korea - Electrode online using the appropriate measure DO in wastewater. - Measuring range: 0-20 pppm - Temperature scale: 0 - 800C - Temperature Sensor: Pt1000 sensor - Maximum pressure: 0.4 Mpa - Body electrode with PPS, 5m long cable - Ren screw ¾ "NPT	1
2	Electrodes ONLINE MULTI-PURPOSE, WITH BODY PPS Model D21 Manufacturer: DYS - Korea - Multipurpose electrode D.O online. - Measuring range: 0 - 20 ppm - Temperature scale: 0 - 800C - Temperature Sensor: Pt1000 sensor - Maximum pressure: 0.3 Mpa - Body electrode with PPS, 5m long cable - Ren screw ¾ "NPT	1
3	Electrodes ONLINE USED IN WATER AND WATER PURITY, BODY BY PPS Model D13F Manufacturer: DYS - Korea - DO electrode using appropriate online measurements in water and purified water. - Scale: 40 ppb - 20 ppm - Temperature scale: 0 - 800C - Temperature Sensor: Pt1000 sensor - Maximum pressure: 0.3 Mpa - Body electrodes SUS316L stainless steel, cable length 5m - Ren PG 13.5 screw	1
4	ACCESSORIES FOR POWER POLE D.O code 21M Manufacturer: DYS - Korea - Includes a bottle of electromagnet poles and three membrane replacement (for electrodes D21)	1
