Life: 500000 Cycle
Height: 8.8 mm
Length: 8.3 mm
Travel: 0.5 mm
Actuator: Round
Features: Process Sealed
Illuminated: Non-Illuminated
Unit Weight: 3.244 g
Contact Form: SPST
Mounting Type: Sealed
Current Rating: 50 mA
Mounting Style: Through Hole
Contact Plating: Silver
Ground Terminal: No
Operating Force: 300 gf
Switch Function: OFF - (ON)
Termination Style: PC Pin
Voltage Rating DC: 12 VDC
Mounting Direction: Right Angle
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
