Direct access to our certified experts
Voltage output range: 100mV; 1V; 10V
Current output (active and passive): 30mA
Frequency output range: 100Hz; 1kHz; 10kHz
Resistive output range: 50Ω; 500Ω; 5000Ω
Pulse output range: 10Hz(1~100000); 1kHz(1~100000); 100kHz(1~100000)
Switch output range: 100Hz(1Hz~110Hz); 1kHz(0.1kHz~1.1kHz); 10kHz(1kHz~11kHz); 100kHz(10kHz~110kHz)
Voltage measurement range: 200mV; 2V; 20V; 200V
Current measurement range: 20mA; 200mA
Frequency measurement range: 100Hz; 1kHz; 10kHz
Resistance measurement (four-wire) range: 50Ω; 500Ω; 5000Ω
Switch measurement: CLOSE/OPEN
HART: have
Use environment: temperature 20℃±2℃, relative humidity≦80%RH
Dimensions of the calibration table: 1880mm (length) × 758mm (width) × 1460mm (height)
Power supply: AC220V±10%, 50Hz±2Hz
Power consumption: <500W
