Main technical indicators
- Display: 3.5-inch color screen (resolution 320*480)
- According digits: 6 1/2
- Signal terminal: Front end
- Measuring range:
+ DCV: 0 mV~1000 V
+ ACV: 1 mV~750 V
+ DCI: 0 uA ~ 12 A
+ ACI: 1 uA ~ 12 A
+ Resistance: 0 Ω ~ 1 GΩ
+ Frequency/period: 3 Hz ~ 1 MHz
+ Capacitance: 0 nF ~ 100 mF
- On- off/diode: Yes
- Proportion (DC:DC):
+ Reference range: 100mV ~ 10 V
+ Input range: 100mV ~ 1000 V
- Temperature:
+ Type: Platinum resistance, thermistor, custom sensor
+ Maximum resolution: 0.001℃
- Mathematical functions: Relative to (ax + b), maximum/minimum/average, standard deviation, dB, dBm, read retention, limit test
- Graphics: Histogram, trend graph
- Interface: RS-232、IEEE 488、LAN、USB Device、USB Host、Trig IN/OUT
- Programming language: SCPI Compatible with Agilent 34401A, 34410 and Fluke 45
- Data storage capacity: 512K
General technical specifications
- Power supply voltage: 220V.AC±10%, 45~66Hz, or 110V.AC±10%, 45~440Hz;
- Function: <20W;
- Display: 3.5 inch TFT LCD screen, resolution 480 *320, color 16M;
- Temperature Range: -5℃~+45℃;
- Humidity range: 5%~85% relative humidity;
- Interfaces: RS232, USB Host, USB Device, LAN, GPIB (only ET3260 support), Wifi, Bluetooth;
- Size and weight: 265mm *105mm *335mm (width *height *depth), weight 2.7Kg.
Standard accessories
- Three core Power Supply Wire*1(30A51);
- Three core pen*1(32A52);
- Backup Power Fuse*2(32A52).
Optional accessories
- GPIB cable (32P01);
- Cabinet Installation Kit (32P02);
- Pt100 temperature probe (32P03);
- Rs232 Serial Port Line (32P04);
- USB data line (32P05).
