Color: Black
Diameter: 29.7 mm
IP Rating: IP65, IP67, IP69K
Shell Size: 12
Wire Gauge: 16 AWG
Shell Style: Straight
Thread Size: 11/16-24 UNEF
Mating Style: Bayonet
REACH - SVHC: Details
Mating Cycles: 500 Cycles
Contact Gender: Without Socket Contacts
Current Rating: 10 A
Housing Gender: Male
Mounting Angle: Straight
Mounting Style: Free Hanging
Shell Material: Polyamide (PA)
Voltage Rating: 500 V
Contact Plating: Gold
Contact Material: Brass
Termination Style: Crimp
Insert Arrangement: 12-08
Flammability Rating: UL 94 V-0
Number of Positions: 8 Position
