Width: 22 mm
Height: 13 mm
Length: 22.48 mm
Core Type: Wirewound
Shielding: Shielded
Tolerance: 20 %
Inductance: 22 uH
Application: Automotive
Termination: Standard
Core Material: Alloy Powder
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 13.5 A
Saturation Current: 16 A
Maximum DC Resistance: 10 mOhms
Self Resonant Frequency: 4 MHz
Maximum Operating Temperature: + 155 C
Minimum Operating Temperature: - 55 C
