Rockwell Test Force: 60kgf (558.4N), 100kgf (980.7N), 150kgf (1471N)
Brinell Test Force: 30kgf (294.2N), 31.25kgf (306.5N), 62.5kgf (612.9N), 100kgf (980.7N), 187.5kgf (1839N)
Vickers Test Force: 30kgf (294.2N), 100kgf (980.7N)
Indenter: Diamond Rockwell Indenter, Diamond Vickers Indenter, ф1.588mm, ф2.5mm, ф5mmBall Indenter
Loading Method: Automatic (Loading/Dwell/Unloading)
Hardness Reading: LCD Screen Display
Test Scale: HRA, HRB, HRC, HRD, HBW1/30, HBW2.5/31.25, HBW2.5/62.5, HBW2.5/187.5, HBW5/62.5, HBW10/100, HV30, HV100
Conversion Scale: HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS, HBW
Magnification: Brinell: 37.5×, Vickers: 75×
Resolution: Rockwell: 0.1HR, Brinell: 0.5μm, Vickers: 0.25μm
Dwell Time: 0~60s
Data Output: Built-in Printer，RS232 Interface
Max. Height of Specimen: Rockwell: 400mm, Brinell: 330mm, Vickers: 345mm
Throat: 165mm
Power Supply: AC220V，50Hz
Execute Standard: ISO 6508，ASTM E-18，JIS Z2245，GB/T 230.2 ISO 6506，ASTM E10-12，JIS Z2243，GB/T 231.2 ISO 6507，ASTM E92，JIS Z2244，GB/T 4340.2
Dimension: 500×225×880mm，Packing Dimension: 650×370×1140mm
Weight: Net Weight: 100kg，Gross Weight: 120kg
Packing List:
Instrument Main Body 1 set
Diamond Rockwell Indenter 1 pc
Diamond Vickers Indenter 1 pc
ф1.588mm, ф2.5mm, ф5mmBall Indenter each 1 pc
Slipped Test Table 1 pc
Middle Plane Test Table 1 pc
Large Plane Test Table 1 pc
V-shaped Test Table 1 pc
15× Digital Measuring Eyepiece 1 pc
2.5×, 5× Objective each 1 pc
Microscope System (include the inside light and outside light) 1 set
Hardness Block 150~250 HBW 2.5/187.5 1 pc
Hardness Block 60~70 HRC 1 pc
Hardness Block 20~30 HRC 1 pc
Hardness Block 80~100 HRB 1 pc
Hardness Block 700~800 HV30 1 pc
Weights 0, 1, 2, 3, 4 5 pcs
Power Cable 1 pc
Fuse 2A 2 pcs
Horizontal Regulating Screw 4 pcs
Level 1 pc
Spanner 1 pc
Screw Driver 1 pc
Anti-dust Cover 1 pc
Usage Instruction Manual 1 copy
