Eyepiece:PL10X/18mm plan eyepiece
Objective:
1. Normal: 5X, 10X, 20X, 40X (195mm)
2. LWD professional plan objective: 5X, 10X, 20X, 50X, 100X) 3. Standard parts: 5X, 10X, 20X, 50X (100X for optional purchase)
Head: Gemel trinocular head, 45 degree inclined, with 8:2 prismatic Interpupillary distance: 55-75mm
Nosepiece:Build-in quadruple nosepiece (Build-in quintuple nosepiece)
Focus:Fine and coarse coaxial, moving range: 33mm, fine precision: 0.001mm
Stage:Size: 180*155mm, moving range: 75*40mm Ø12 metal stage (Ø25 metal stage for optional purchase)
Illumination:
1. Reflected Kohler illuninator with iris aperture diaphragm and centering field diaphragm.
2. 100-240VAC power supply with 3W LED bulb (6V30W halogen bulb for optional)
3. Brightness is adjustment
Polarizing set:Analyser can be rotatable and both polarizer and analyser can be move light path
Filter:Blue, green, yellow
Operation Environment:
l Indoor
l Altitude: 2000m Max.
l Temperature: 5℃-40℃ (41℉-104℉)
l Humidity: 80% for 31℃ (88℉); 70% for 34℃ (93℉); 60% for 37℃ (99℉); 50% for 40℃ (104℉)
l Pollution: 2 (Refer to IEC664)
