Measuring Range: 1.0~6000mm
Resolution: 0.01mm(<100mm) 1mm(>100mm)
Velocity: 500~20000m/s 20 fixed velocity
Delay: -20~3400us /resolution : 0.1us
Probe Delay: 0~99us /resolution: 0.01us
Linear Error: Horizontal error≤0.1% Vertical error≤3%
Dynamic Range: ≥36dB
Sensitivity: ≥64dB 200mmФ2 flat-bottomed hole
Matched Damp: 50/150/400Ω
Measuring mode: Peak/Verge
Detector Pattern: 0~110dB 0/0.1/0.2/0.5/1/2/6/12/ RF/Full-Wave/Positive/Negative/ half-wave
Bandwidth: 0.3~1/0.5~4/2~15MHZ
Screen Update Rate: ≥60Hz
Alarm: Independent logic gate alarm, alarm threshold thickness measurement
Sluice gate: Two Separated Gate A/B
Measured value display: 5 measured value display area, where a main display area, Selectable measurement value content SA/SB/DA/DB/PA/PB/A%A/A%B/dBtA/dBtB/dBrA/dBrB/SBA/DBA/PBA/LA/LB
Working Environment: Temperature：-20℃~70℃ Humidity：5%～90%
Dimension: 180×150×50mm
Weight: 1.0 Kg（including battery pack）
