Capacity
KN: 2kN
KG: 200kg
Structure: Double rail structure
Unit switching: G, Kg, lb, N, KN
Displacement unit switching: Inch, cm, mm
Test machine level: 1class
Effective force range: 0.4％～ 100％FS
Force accuracy: Within ±0.5%
Force decomposition: 1/200 000
Force Power magnification: X1, X2, X5, X10, X20, X50, X100., etc. Seven-speed automatic shifting
Displacement resolution: 0.05mm
Displacement accuracy: Within ±1%
Deformation measurement range: 2%～ 100%FS
Deformation indication accuracy: Within ±1%
Large deformation measurement range: (0～ 800)mm
Large deformation resolution: 0.05mm
Large deformation indication error limit: Within ±1%
Maximum test speed: 500mm/min, optional maximum 1000mm/min
Minimum test speed: 0.1mm/min
Speed accuracy: Within ±1%
Beam travel height
standard: No grip testing stroke： 920mm
optional: No grip testing stroke： 1320mm
Fixture configuration: One set of tensile grip； can choose other grips
Returning method: Manual or automatic selection, automatically return after the test ends or manually return to the initial position
Stop method
1.Maximum break value automatically stop 2.Upper and lower limit safety setting stop
Safety devices
1.Mechanical limit switch protection
2.Emergency stop switch emergency brake
Overload protection: Over 10% of maximum load, automatic machine protection
Accessories: 1 power cord; 1 manual; 1 certificate
Optional accessories Anti-splash device (protective door); printer;software
Powder supply: 220V.AC/ 50HZ; 110V.AC/60HZ
Main host size/ weight
Standard model: Length*Width*Height: 450mm*400mm*1160mm / Around 50KG
Heightening model: Length*Width*Height: 450mm*400mm*1550mm / Around 55KG
