Resolution:0.5μm
Objective:10X (Observe) 20X (Measure)
Eyepiece:10X
Total Magnification:100X, 200X
Test Range1HV~2967HV
Turret:Automatic Shifting
Loading Method:Automatic (Loading/Dwell/Unloading)
Dwell Time:0~60s
Light Source:Halogen Lamp
Test Force:
0.3kgf, 0.5kgf, 1kgf, 2kgf, 2.5kgf, 3kgf, 5kgf, 10kgf 2.94N, 4.90N, 9.80N, 19.6N, 24.5N, 29.4N, 49N, 98N
Max. Height:170mm
Throat depth:130mm
Power Supply:AC220V，50Hz
Execute Standard:ISO 6507，ASTM E92，JIS Z2244，GB/T 4340.2
Dimension:530×280×630mm，Packing Dimension: 620×450×740mm
Weight:Net Weight: 44kg，Gross Weight: 58kg
Packing List:
Instrument Main Body1 set
10× Reading Microscope1 pc
Diamond Vickers Indenter1 pc
10X，20X / 40X ojectiveeach 1 pc
Big Plane Test Table1 pc
V-shaped Test Table1 pc
Power Cable1 pc
Level1 pc
Horizontal Regulating Screw4 pcs
Halogen Lamp12V、15~20W1 pc
Fuse1A2 pcs
Screw Driver1 pc
Inner Hexagon Spanner 2.5mm1 pc
Hardness Block2 pcs
Anti-dust Cover1 pc
Instruction Manual1 pc
