Measurement Operating Ranges:
Relative Humidity: 5 to 95%
Temperature: 10°C to 50°C
Dew/Frost Point: -40°C to 60°C with D2 sensor
Accuracy:
Relative Humidity: ±0.5%
Temperature: ±0.1°C
Dew/Frost Point: ±0.2°C nominal
Chilled Mirror Temperature Sensors: 3-wire platinum resistance thermometer (PRT), 100 ohms at 0°C, nominal
Depression: 50°C (122°F), nominal with D2 sensor
Slew Rate: 1.0°C (1.8°F)/second max., above 0°C
Repeatability: ±0.05°C
Hysteresis: Negligible
Power Requirements: 100 to 240 Vac, 50-60 Hz, 150 W maximum
Sample Flow Rate: 1 liter/minute (2.0 SCFH) nominal
Operating Temperature:
Control Unit: 0°C to +50°C (+32°F to +122°F)
Outputs:
Analog: 0 to 5 Vdc or 4 to 20 mA
Serial: RS232C
Display: Multi-line graphical LCD
Sample Chamber Probe Port Diameters:
Standard Port Sizes for RH Probes: 10, 12, 18 mm, 1/2, 3/4 in. diameter
Standard Port Sizes for Dew/Frost Point Probes: 1/2 to 1 1/4 in. diameter
Custom Port Sizes: Available
Weight: 15.4 kg (34 pounds)
Dimensions: 20 5/8 in. W x 17 3/16 in. D x 8 9/16 in. H (52.4 cm W x 43.7 cm D x 21.7 cm H)
