Elcometer K0006075M001 Portable Sphere Spectrophotometer (0,40 ΔE * ab)

Name: Elcometer K0006075M001 Portable Sphere Spectrophotometer (0,40 ΔE * ab)
Brand: ELCOMETER

ManufacturerELCOMETER(View more products from this manufacturer)

ModelK0006075M001

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Measuring Geometrics: d/8°, DRS spectral engine, fixed aperture: 8mm viewing/12mm illumination
Light Source: Gas filled tungsten lamp
Illuminant Types: C, D50, D65, D75, A, F2, F7, F11, F12
Standard Observers: 2° and 10°
Spectral Range: 400-700nm
Memory: 1,024 standards with tolerances, 2,000 samples
Measurement Range: 0 to 200% reflectance
Measuring Time: Approximately 2 seconds
Inter-Instrument Agreement: 0.40 ΔE*ab
Repeatability: 0.10 ΔE*ab on white ceramic (standard deviation)
Lamp Life: Approximately 500,000 measurements
Power Supply: Removable (Ni-metal hydride) battery pack; 7.2DC rated @1450mAh
Measurements per Charge: 1000 measurements within 8 hour period
Weight: 1.1kg
Dimensions: 109 x 83 x 195mm
Certificate Available Certificate of Calibration: issued for Fixed Calibration equipment and shows readings and traceability
Packing List: Elcometer 6075/1, calibration standards, AC adaptor, carry case & operating instructions

Datasheet

Elcometer 6085 Portable Sphere Spectrophotometer

The Elcometer 6085 is an affordable sphere spectrophotometer, designed to give fast, precise and accurate colour measurement information on materials ranging from paper and paint to plastics and textiles.

Lightweight, compact, portable instrument
Diffuse/8° sphere optical geometry
Fixed 8mm aperture
Large, easy-to-read high res graphical colour LCD display
Opacity and colour strength measurement
Simultaneous measurement of both specular component included and specular component excluded
Rugged construction
Reliable detent lock
Rechargeable battery for remote use

Elcometer 6085 Portable Sphere Spectrophotometer

Technical Specification

Part Number	Description	Certificate
K6085M001	Elcometer 6085 Ci60 Portable Sphere Spectrophotometer	•
K6085M002	Elcometer 6085 Ci62 Portable Sphere Spectrophotometer	•
Measuring Geometrics	d/8°, DRS spectral engine, fixed 8mm aperture Simultaneous SPIN / SPEX
Light Source	Gas filled tungsten lamp
Illuminant Types	A, C, D50, D55, D65, F2, F7, F11 & F12
Standard Observers	2° and 10°
Spectral Range	400-700nm
Memory	1,000 standards with tolerances, 4,000 samples
Measurement Range	0 to 200% reflectance
Measuring Time	Approximately 2 seconds
Inter-Instrument Agreement (Ci60)	CIE Lab: Avg. 0.40 ∆Eab based on average of 12 BCRA Series II tiles (specular component included) Max. 0.60 ∆E*ab on any tile (specular component included)
Inter-Instrument Agreement (Ci62)	CIE Lab: Avg. 0.20 ∆Eab based on average of 12 BCRA Series II tiles (specular component included) Max. 0.40 ∆E*ab on any tile (specular component included)
Short-term Repeatability*	Ci60 - 0.10 ∆Eab on white ceramic (standard deviation) Ci62 - 0.5 ∆Eab on white ceramic (standard deviation)
Lamp Life	Approximately 500,000 measurements
Power Supply	Removable battery pack; 7.4 VDC, 2400 mAh
Measurements per Charge	1000 measurements within 8 hour period
Weight	1.05kg (2.32lbs.)
Screen Display	3.2 inch backlit Colour Graphic LCD
Dimensions	109 x 91 x 213mm (4.3 x 3.6 x 8.4”)
Packing List	Elcometer 6085 Ci60, calibration standards, calibration certificate for standards, AC adaptor, mains leads (UK & EUR), carry case & operating instructions
Packing List	Elcometer 6085 Ci62, calibration standards, calibration certificate for standards, AC adaptor, mains leads (UK & EUR), carry case & USB cable, operating instructions
