Temperature Range:
0 °C – 120 °C (32 °F – 248 °F) with Peltier technology – No external cooling required
Optional extension EV01-COOL: -20 °C – 120 °C (-4 °F – 248 °F) – External cooling required
Temperature Stability: 0.01 °C (0.02 °F)
Pressure Range EV10 ERAVAP: 0 kPa – 1 000 kPa (0 psi – 145 psi) – High precision pressure transducer
Pressure Resolution: 0.01 kPa (0.0014 psi)
Sample Volume: 1 mL (2.2 mL per rinsing cycle)
Measurement Time: 5 minutes for a standard measurement
Vapor / Liquid Ratio: Variable from 0.02/1 – 100/1 (Method dependend)
Precision Repeatability: r ≤ 0.15 kPa (0.022 psi); Reproducibility: R ≤ 0.5 kPa (0.073 psi) measured with cyclopentane @ 37.8 °C
Power Requirements: Auto-switching 85 – 264 V AC, 47 – 63 Hz, max. 150 W (multi-voltage power supply)
Dimensions (W x H x D) / Weight: 29 x 35 x 34 cm (11.4 x 13.8 x 13.4 in) / 9.7 kg (21.4 lb)
