Nominal Size: 1.2 meter
External Dimensions (W x D x H): 1340 x 736 x 1485 mm
Internal Work Area (W x D x H): 1268 x 596 x 765 mm
Standard Filtration Elements:
Pre-filter: Disposable, non-washable polyester fibre, 85% arrestance, EU3 rated
Main filter: Activated Carbon with Granular Media bed (8 different filter types available, codes A-H)
Back-up Filter: HEPA filter, typical efficiency of >99.99% at 0.3 microns, removes particles and aerosols
Total Weight of Carbon Filter: 2 x 13.9 Kg each
Control System: Esco Sentinel™ Silver Microprocessor Controller
VOC Sensor: Optional
Airflow alarm: yes
Auto-Purge Slots: yes
Inflow Air Velocity: 0.40 m/s - 0.6 m/s (80-120 fpm)
Sound Emission: ≤65 dBA
Fluorescent Light Intensity: >1107 lux
Hood Construction:
Main Body: 1.2 mm (0.05") 18 gauge electro-galvanized steel with white oven-baked epoxy-polyester IsocideTM antimicrobial powder coated finish
Side Walls: Tempered Glass
Work Top: 1.5 mm (0.06") 16 gauge stainless steel, type 304, with 4B finish
Sash:
Sloped Front: 3°
Sash Type: Vertical Sliding or Optional Motorized Sash
Electrical:
220-240 VAC, 50 Hz, 1Φ
Cabinet Full Load Amps (FLA): 2 A
Optional Outlets (FLA): 5 A
Cabinet Nominal Power: 290 W
Cabinet BTU/Hr: 990
Net Weight (Hood only, excludes optional stand): 225 kg
