Nominal Size: 1.2 meters
External Dimensions (W x D x H): 1420 x 846 x 2190 mm
Internal Work Area Dimensions (W x D x H): 1270 x 620 x 670 mm
Usable Work Area: 0.60 m²
Tested Opening: 203 mm
Maximum Sash Opening: 440 mm
Average Airflow Velocity:
Inflow: 0.45 m/s (90 fpm)
Downflow: 0.30 m/s (60 fpm)
Exhaust Volume with Ducting:
Inflow: 0.45 m/s (90 fpm)
Downflow: 0.30 m/s (60 fpm)
CBV Exhaust Volume: 611 m³/h
Static Pressure at CBV Exhaust Volume: 39 Pa / 0.15 in H₂O
ULPA Filter Typical Efficiency:
Downflow: >99.9995% for particle size at 0.3 µm as per IEST-RP-CC001.3 USA
Exhaust: 99.999% for particle size at 0.1 to 0.2 µm as per IEST-RP-CC001.3 USA
HEPA V-bank Filter Typical Efficiency:
Exhaust: 99.999% at 0.3 µm as per IEST-RP-CC001.3 USA
Sound Emission per EN 12469: 61 dBA
Fluorescent Lamp Intensity at Zero Ambient: >1300 Lux
Cabinet Construction:
External: 1.5 mm (0.06") 16 gauge electrogalvanized steel with Isocide white oven-baked epoxy powder-coating
Internal: Stainless steel Type 304 with No.4 finish, 1.5 mm (0.06") / 16 gauge thick
Net Weight: 383 kg
Electrical: 110-120V,AC, 60 Hz, 1Ø
Cabinet Full Load Amps (FLA): 11A
Optional Outlets FLA: 5A
Cabinet Nominal Power: 653W
Cabinet BTU: 2228 BTU/hr
