110-120 VAC, 50/60 Hz, 1Ø
Nominal Size: 1.2 meter
External Dimensions: (W x D x H)
Fume Hood unit only: 1220 x 1000 x 1400 mm
With Exhaust Collar: 1220 x 1000 x 1521 mm
With Fully-opened Sash: 1220 x 1000 x 1603 mm
Internal Dimensions: (W x D x H) 996 x 775 x 1230 mm
Exhaust Outlet Diameter and Material: 305 mm (12.0”), Fiberglass
Number of Exhaust Collars: 1
Fluorescent Lamp Intensity: 930 lux
Construction:
Main Body: Electrogalvanized steel with Epoxy-polyester hybrid Isocide™ powder coating
Internal Liner (default): Esco Resinate Plus™
Worktop (default): Ceramic Worktop
Sash Specifications:
Sash Material: Laminated-Tempered and Framed Safety Glass
Sash Configuration: Combination
Sloping: 5° Sloped
Maximum Sash Opening: 670 mm (26.4”)
Electrical:
Cabinet Full Load Amps (FLA): 32 A
Cabinet Nominal Power: 100 W (lighting only)
Net Weight (Fume Hood unit only. Excludes base cabinet/optional stand): 255 Kg
