Stainless Steel Side Walls: 220-240 VAC, 50/60 Hz
Nominal Size: 1.2 meter
External Dimensions (W x D x H):
Without Arm Rest: 1340 x 815 x 1570 mm
With Arm Rest: 1340 x 873 x 1570 mm
Internal Dimensions (W x D x H): 1220 x 625 x 720 mm
Usable Work Area: 0.63 m²
Sash Opening: Available in 254 mm (10")
Maximum Sash Opening: 570 mm
Average Airflow Velocity:
Inflow:
254 mm (10”): 0.53 m/s
Downflow:
254 mm (10”): 0.30 m/s
Average Airflow Volume:
Inflow:
254 mm (10”): 591 m3/h
Downflow:
254 mm (10”): 848 m3/h
Exhaust:
254 mm (10”): 591 m3/h
ULPA Filter Typical Efficiency: >99.999% for particle size between 0.1 to 0.3 microns
Sound Emission (dBA): NSF / ANSI 49
254 mm (10”): 59
Light Intensity: Main body - >1200 lux (11 ft. candles)
Cabinet Construction:
Main body: Electro-galvanized steel with white oven-baked epoxy-polyester Isocide™ antimicrobial powder-coated finish, 1.5 mm (0.06”) / 16 gauge thick
Work Zone: Stainless steel type 304 with no.4 finish, 1.5 mm (0.06”) / 16 gauge thick
Electrial
Full Load Amps (8) exclude 5A EO
254 mm (10”): 10 A
Net Weight: 287 Kg
