110-120 VAC, 50/60 Hz, 1Ø
Nominal Size: 1.5 meter
External Dimensions (W x D x H)
Fume Hood unit only: 1500 x 900 x 1500 mm
With Exhaust Collar: 1500 x 900 x 1681 mm
With Fully-opened Sash: 1500 x 900 x 1879 mm
Internal Work Area, Dimensions: (W x D x H) 1280 x 665 x 1200 mm
Exhaust Volume/Static Pressure Required at 0.5 m/s (100 fpm) at Full Open Sash: 1705 cmh at 95 Pa
Exhaust Outlet External Diameter: 300 mm (11.8”)
Number of Exhaust Outlet: 1
Light Intensity at Work Surface: 935 lux
Controller: Rocker Switches (Option to upgrade to Sentinel™ XL)
Construction:
Main Body: Polypropylene
Internal Liner: Polypropylene
Worktop (default): Polypropylene
Sash Specification:
Sash Material: Polycarbonate
Sash Configuration: combination
Sloping: 5° slope
Maximum Sash Opening: 790 mm (31.1”)
Electrical:
Cabinet Full Load Amps (FLA): 32 A
Cabinet Nominal Power: 25W (lighting only)
Net Weight (Fume hood unit only. Excludes base cabinet/ optional stand): 140 Kg
