System: 2-zone transition by vertical transfer of specimens
Performance:
Test area:
Hot exposure range: ＋60 to ＋200℃ (＋140 to ＋392℉)
Cold exposure range: −65 to 0℃ (−85 to ＋32℉)
Temp. fluctuation: ±0.5℃
Hot chamber:
Heat up time: Ambient temp. to +200°C within 30 min.
Cool chamber:
Pull down time: Ambient temp. to –80°C within 90 min.
Temp. recovery: within 5 min.
Inside Dimensions: W320×H148×D230mm (12.6×5.8×9 inch)
Outside dimensions: W680×H1745×D1050mm (26.8×64×41.3 inch)
Inner volume of test area: 10.9 L
Weight: Approx. 400 kg
Utility requirements:
Ambient temp. range: 0 to ＋40℃ (＋32 to ＋104℉)
Power supply: 380V AC 3φ 50Hz: 17 A
400/415V AC 3φ 50Hz: 17 A
Exhaust heat rate: 17,585kJ/h (4200 kcal/h)
INCLUDED ACCESSORIES:
● Specimen basket:
(18-8 Cr-Ni stainless steel, 5 mesh metal basket) W320×H35×D230mm /load capacity: 2kg: 2
● Cartridge fuse: 3A, 5A,7A (380/400/415V AC): 1each
● Cable port rubber plug: 2
● Wirefisher : 1
● Operation manual : 1
