Power Supply: Host: 14.8V 5200mAh lithium battery; detection clamp: 3.7V 2600mAh lithium battery
Displayer: 7 inch true-color LCD, 153.8mm×85.6mm
Measurement Method: Clamp type CT
Output Voltage: AC 3000V/8000V
Output Current: ≤50mA
Earth Fault Resistance: ≤150kΩ
Line Reactance: ≤30MΩ
Output Frequency: 50Hz
Clamp Jaw Size: Φ36mm
Electricity Verification Alarm: Detect whether the tested cable is live, emit sound and light alarm if live.
Voice Broadcast: Yes
Communication Method: 433MHz wireless communication
Wireless Communication Distance: 50m(in open environment)
Bluetooth Communication Distance: 40m(in open environment)
Data Upload: The host has a USB interface for uploading test data.
Automatic Shutdown: The detector will automatically shut down after 15 minutes of no-operation.
Battery Level Display: Display the battery level of host and detection clamp.
Detector Size: Host: 355mm×272mm×164mm; Detection clamp: 297mm×118mm×94mm
Weight: Host: about 7610g; detection clamp: about 785g; total weight: 17.4kg (include insulation rod)
Battery Level: Display the battery level of host and detection clamp.
Working Height: Altitude <5000m
Insulating Rod Size: About 4300mm
Working Temperature & Humidity: Temperature: -20℃~70℃; Humidity: 5~90％RH
