Power Supply: DC 14.8V 5200mAh rechargeable lithium battery
Measurement Mode: Automatic & Manual
Display Range: 1.0uΩ~50.00kΩ
Range & Test Current
200.0uΩ~50.00kΩ | AUTO
200.0uΩ~20.00mΩ | 10A | 0.2%FS
10.00mΩ~200.0mΩ | 5A | 0.5%FS
100.0mΩ~2.000Ω |1A | 1%FS
1.00Ω~20.00Ω | 100mA | 1%FS
10.00Ω~200.0Ω |10mA CVT |1%FS
100.0Ω~50.00kΩ | 1mA CVT| 1%FS
Max Resolution: 0.1uΩ
Measurement Accuracy: 0.2%
Test Current Gear: 10A, 5A, 1A, 100mA, 10mA, 1mA, AUTO
Output Voltage: 24V MAX
Alarm Setting: Alarm critical value setting range; 1mΩ~2500Ω, 0Ω is not start the alarm function. Do not active the alarmfunctionevery starting up the tester
Alarm Warning: When the test value exceeds the alarm setting value, the buzzer will have alarm sound prompt
Low Voltage Indication: When battery voltage drops to DC 14.8V±0.1V, low battery voltage symbol will display and remind to charge intime
Data Storage: 600 groups (data will not be lost after power failure or battery replacement)
Automatic Shutdown: After setting automatic shutdown, 15 minutes without any operation after starting up will automatic shutdown
LCD Dimension: 128mmX75mm; Display area:124X67mm
Host Dimension: 280mmX260mmX160mm
Weight: Total weight: 5.8kg(include all accessories)
Bluetooth Communication: Yes
USB Interface: With USB interface, software monitoring, storage data can be uploaded to computer, save and print. Withstand Voltage: AC 3700V/rms(between the housing and screws)
Accessories: Tester: 1PCS; Test line: 2PCS; USB communication cable: 1PCS; Special charger: 1PCS; Tool bag : 1PCS
