Power Supply: Rechargeable lithium battery pack 9.6V, external battery charger.
Display Mode: LCD true-color screen, 640dots×480dots, 5.6 inch, display area 116mm×88mm.
Battery Level Indication: The battery symbol 5 cells displays the battery levels. When the battery level is lower, it will shut down automatically after 1 minutes.
Working Current: About 490mA, The battery works continuously for about 8 hours at full power.
Clamp Jaw Size:
008B Pointed small current clamp: Φ8mm; (option)
040B Round mouth current clamp: 35mm×40mm; (option)
068B Round mouth current clamp: 68mm×68mm; (option)
300F Flexible coil current sensor: Φ300mm; (option)
Number Of Channels: 4 channels of current and voltage
Line Voltage: 1.0V~2000V
Phase Voltage: 1.0V~1000V
Current:
008B Current clamp: 10mA~10.0A; (option)
040B Current clamp: 0.10A~100A; (option)
068B Current clamp: 1.0A~1000A; (option)
300F Flexible coil current sensor: 10A~6000A (option)
Frequency: 40Hz~70Hz。
Electricity Quantity Parameters: W, VA, Var, PF, DPF, cosφ, tanφ.
Electric Energy Parameters: Wh, Varh, Vah.
Harmonic: Yes, 0~50times.
Total Harmonic Distortion: Yes, 0~50times, each phase.
Number Of Transient Recording Groups: 150 groups.
Voltage Flicker: Yes
Starting Current Mode: Yes, 100 seconds.
Three-phase Imbalance: Yes
Record: 300 days (record 20 parameters at the same time, record 1 parameter every 1 minute).
Min Max Record Value: Yes, the maximum and minimum values can be measured over a period of time.
Alarm: 40 different types of parameters can be selected, and 12,800 sets of alarm logs.
Peak Value: Yes
Screenshot Capacity: 60 PCS
Menu Language: Chinese and English.
SD Memory Card: 2G
Communication Interface: USB
Automatic Shutdown: In the alarm/trend chart recording/transient capture mode (pending or in progress), the instrument will not automatically shut down.
In other test mode, no button operation within 15 minutes, automatically shut down after 1 minute prompt.
Backlight Function: Yes, it is suitable for use in dim place and at night.
Meter Size: 240mm×170mm×68mm
Weight: Host: about 1.6kg (include battery); total weight: about 9.18kg (include package and accessory).
Input ImpedanceInput impedance of the test voltage: 1MΩ.
Withstand Voltage: The sine wave AC voltage of 3700V/50Hz withstand between the instrument circuit and the housing for 1 minute.
Insulation: The distance between the instrument circuit and the protective case ≥ 10M Ω.
Suitable Safety Standard: IEC 61010 1000V Cat III / 600V CAT IV, IEC61010-031, IEC61326, Pollution Level 2.
Working Temperature & Humidity: -10℃~40℃; below 80%RH.
Store Temperature & Humidity: -10℃~60℃; below 70%RH.
