Power Supply: DC6V alkaline dry battery (1.5V AAA×4)
Display Mode: 4-digit LCD display, backlight function, suitable for dim place
LCD Size: 47mm×28.5mm
Measurement Method: Clamp CT, integration method
Transmission Mode: 433MHz Wireless transmission distance 30m
Clamp Jaw Size: Φ33mm
Measurement Range: AC 0.00mA~600.0A
Current Frequency: 50Hz/60Hz automatic
Solution: 0.01mA
Shift Gear: 0.00mA~600A Fully automatic shift gear
Test Accuracy:
0.00mA~100A: ±1%rdg±5dgt
101A~600A: ±2%rdg±5dgt
Memory: 99 groups, in storage process “MEM” symbol display, “FULL” symbol flicker indicate storage full
PEAK Hold: Automatically hold the test value at high point. Usually Press PEAK key in the test mode ,the PEAK lamp lights up. The peak hold function is enabled, press PEAK key again to cancel this function.
Line Voltage: Suitable for circuit testing with insulated skin below 10kV, and bare wire or busbar below 35kV.(Operation with insulating rod)
Data Hold: Press HOLD key to hold data in test mode, “HOLD" symbol display, press HOLD key again to cancel this function.
Data Access: "MR" symbol display, can look up all storage data
Sampling Rate: 2 times/second
Overflow Display: Exceed measure range overflow function:"OL A" symbol display
Automatic Shutdown: After 15 minutes power on, the meter shuts down automatically without any operation to reduce battery consumption
Battery Voltage: When battery voltage is lower than 4.8V, low battery voltage symbol display and remind to replace battery.
Meter Size: 72mm×245mm×39mm
Weight:
Meter: about 355g (include battery),
Receiver: about 330g(include battery),
Total weight: about 900g(include accessory)
Interference: No 315MHz, 433MHz same frequency signal interference
Telescoping Insulating Rod Size: About 900mm (3 PCS)
Insulation Strength: AC 60kV/rms (The telescopic insulating rod is completely pulled apart, between the two ends)
Structure: Anti-drip typeⅡ
Working Temperature & Humidity: -20℃~40℃; below 80%RH
Storage Temperature & Humidity: -20℃~60℃; below 70%RH
