Wavelength:
Operating wavelength range (nm) : 1260 to 1360
Wavelength accuracy:
+ Absolute (pm): ±5
+ Relative (pm): ±1
Optical ports (front panel):
TLS inputs and outputs:
+ Number of input ports: 1 (PM13)
+ Number of output ports: 1 (PM13)
+ Connector type: FC/APC narrow key
+ Polarization extinction ration (PER): ≥20 dB
Detector array:
+ Number of detector ports: 1, 2 or 4
+ Connector type: FC/PC wide key
Electrical ports (rear panel):
+ Trigger out (5 V TTL): Swept measurement external synchronization (pulse train generated at native sampling resolution)
+ Trigger in (5 V TTL): Triggered measurement without laser sweep control (measurement is taken when TTL level = high)
+ Analog voltage in (0-5 V high impedance): Voltage level sampling from an external device (sampling resolution of 1.3 mV)
Optical power:
Power range:
+ On TLS input (dBm): 0 to 10
+ On detector ports (dBm): –60 to 7
Transfer function:
+ Accuracy (dB): ±0.2
+ Sampling resolution (dB): 0.02
+ Dynamic range: 65 dB typical
Polarizationdependent loss:
+ Accuracy (dB): n/a
+ Measurement range: n/a
+ Repeatability: n/a
Sampling characteristics:
+ resolution (pm): 1 to 250
+ Native Sampling resolution:
+ Compatible sweep speed of TLS (nm/s) :
Data handling:
+ Interface with PC / Data rate: USB-B 2.0 / 4 MBaud
+ Maximum Number of transfer function Data points PER TLS PER detector as a function of Number of activated detectors by software: 260,000 for 1 detector; 219,500 for 2 detectors; 164,400 for 3 detectors; 131,100 for 4 detectors; 110,500 for 5 detectors
Environment:
+ Temperature: Operating: 15 °C to 30 °C (59 °F to 86 °F)
+ Temperature: Storage: –10 °C to 60 °C (14 °F to 140 °F)
+ Relative humidity: < 80 % non-condensing
+Power supply: AC 100 V to 240 V (50 Hz to 60 Hz)
+Dimensions (W x h x D): 440 mm x 50 mm x 375 mm (17.3 in x 2 in x 14.8 in), including rackmounting brackets
+Weight: Between 3.5 kg and 3.9 kg (7.7 lb to 8.6 lb), depending on model
