TECHNICAL SPECIFICATIONS
Measured wavelength range (nm): 1475 to 1626
Dynamic range (dB): 25 (32 with reflector)
Distance uncertainty (km): ±(0.01 + 1 % x distance)
Chromatic dispersion
Number of test points: 8
CD uncertainty (ps/nm): ±10
Test time (s): 40
PMD
PMD display range (ps): up to 50
PMD range (strong mode coupling) (ps): 0.1 to 20
PMD uncertainty (strong mode coupling) (ps) : ± (0.2 + 5 % x PMD)
Test time (s): <180
GENERAL SPECIFICATIONS
Size (H x W x D): 96 mm x 50 mm x 281 mm (3 ¾ in x 2 in x 11 in)
Weight: 1.3 kg (2.8 lb)
Temperature
Operating: 0 °C to 50 °C (32 °F to 122 °F)
Storage: —40 °C to 70 °C (–40 °F to 158 °F)
Relative humidity: 0 % to 95 % non-condensing
