SPECIFICATIONS:
Switch : 1×8
Insertion loss (dB) at 1310 nm: 1.2
Insertion loss (dB) at 1530 nm to 1650 nm : 1
Operating wavelength (nm) : 1240 to 1680
Repeatability (dB) : ±0.02
Backreflection (dB)(typical) : –50 (–55)
Crosstalk (dB) (typical): 50 (60)
Polarization-dependent loss (dB) (typical) : 0.09 (0.06)
Switching time (ms) : 30
Fiber type Singlemode : 9/125 µm
Input power (damage threshold) (dBm): 27
GENERAL SPECIFICATIONS:
Switch: 1×8
Number of slots: 2
Dimensions (HxWxD): 50 mm (2 in) x 159 mm (6 1/4 in) x 185 mm (7 5/16 in)
Switch life: 1 billion (109) cycles minimum:
Temperature:
operating: 0 °C to 40 °C (32 °F to 104 °F)
storage: —40 °C to 70 °C (—40 °F to 158 °F)
Maximum relative humidity: 80 % non-condensing at 40 °C
Instrument drivers : IVI drivers, SCPI commands and REST API
Remote control : Via LTB and FTB platform services: GPIB (IEEE-488.1, IEEE-488.2), Ethernet and RS-232
Standard accessories: User guide f, certificate of compliance and calibration certificate
