EXFO MAX-860G Ethernet And Transport Testing

Size (H x W x D) : 210 mm x 254 mm x 66 mm(8 ¼ in x 10 in x 2 5/8 in)

Weight (with battery): 2.5 kg (5.6 lb)

Temperature:

Operation: 0 °C to 40 °C (32 °F to 104 °F)

Storage b: –40 °C to 70 °C (–40 °F to 158 °F)

Relative humidity: 0% to 95%, non-condensing

Processing: Quad-core processor / 8 GB RAM / Windows 10

Display: Multitouch, widescreen, color, 1280 x 800 TFT 203 mm (8 in)

Interfaces: RJ45 LAN 10/100/1000 Mbit/s; Two USB 2.0 ports; One USB 3.0 port; Micro SD card slot; 3.5 mm headset/microphone port

Storage: 128 GB internal memory (flash)

Battery: Rechargeable Li-ion smart battery

Power supply: AC/DC adapter, input: 100–240V; 50/60 Hz; 2.5 A max, output: 24 V; 3.75 A
