GENERAL SPECIFICATIONS
Display: Touchscreen TFT LCD with backlight 152 mm (6 in) diagonal; 800 x 480 resolution, WVGA
Test connections: Five-color banana connector for T/A, R/B, G, T1/A1, R1/B1
Results management:
> 2 GB internal memory
Single and bulk file export to USB memory devices
FTP upload
Temperature
Operating: 0 °C to 40 °C (32 °F to 104 °F)
Storage: –20 °C to 60 °C (–4 °F to 140 °F)
Relative humidity :5 % to 95 %, non-condensing
Shock: 1 m (39 in) drop per GR-196-CORE
Altitude: 3000 m (9842 ft)
Input power: 12 VDC, 4.16 A, 48 W via 90-264 VAC adapter or 12 V vehicle adapter
Battery: Internal rechargeable lithium polymer, with battery-state and level indications, adjustable auto-power down
Safety: CE and CSA marked
Size (H x W x D): 254 mm x 124 mm x 62 mm (10 in x 4 7/8 in x 2 7/16 in)
Weight (with battery): 1.5 kg (3.3 lb)
Water/dust ingress: Designed to comply with IP54
Differential voltage protection : 354 Vrms or 1000 VDC max
Common mode voltage protection: 354 Vrms or 1000 VDC
Voltage detection: >20 V will trigger alarm message
Self-test: Routine on power-up
Connectivity:
USB 2.0 client ports (2)
USB type B host port (1)
Optional WiFi support
Languages: English, French, German, Italian, Polish and Spanish
