Specifications
Resistance:
20mΩ;0.01mΩ;1A;±(0.2% + 6d)
200mΩ;0.1mΩ;1A;±(0.2% + 4d)
2Ω;0.001Ω;100mA;±(0.2% + 4d)
20Ω;0.01Ω;10mA;±(0.2% + 4d)
200Ω;0.1Ω;1mA;±(0.2% + 4d)
2kΩ;0.001kΩ;100μA;±(0.2% + 4d)
20kΩ;0.1kΩ;10μA;±(0.2% + 4d)
Power: 110VAC, 60Hz or 220VAC 50Hz
Dimensions/Weight: 11 x 8.3 x 3.5" (280 x 210 x 90mm)/ 4.85lb (2.2kg)
