Width: 9.65 mm
Height: 4.83 mm
Length: 10.67 mm
Fall Time: 65 ns
Rise Time: 140 ns
Technology: Si
Unit Weight: 4 g
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 98 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 208 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 62 ns
Typical Turn-Off Delay Time: 230 ns
Id - Continuous Drain Current: 20 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Rds On - Drain-Source Resistance: 190 mOhms
Vds - Drain-Source Breakdown Voltage: 600 V
Vgs th - Gate-Source Threshold Voltage: 3 V
