Width: 2.05 mm
Height: 0.55 mm
Length: 2.05 mm
Fall Time: 3.3 ns
Rise Time: 3 ns
Technology: Si
Unit Weight: 40 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 10 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2.4 W
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 8.5 ns
Typical Turn-Off Delay Time: 27 ns
Id - Continuous Drain Current: 9.5 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 36 S
Rds On - Drain-Source Resistance: 60 mOhms
Vds - Drain-Source Breakdown Voltage: 20 V
Vgs th - Gate-Source Threshold Voltage: 400 mV
