Width: 1.25 mm
Height: 0.9 mm
Length: 2 mm
Unit Weight: 5 mg
Configuration: Single
Mounting Style: SMD/SMT
Transistor Polarity: NPN
Pd - Power Dissipation: 200 mW
Typical Input Resistor: 47 kOhms
Typical Resistor Ratio: 2.1
DC Current Gain hFE Max: 56
Peak DC Collector Current: 100 mA
Emitter- Base Voltage VEBO: 10 V
Continuous Collector Current: 100 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
DC Collector/Base Gain hfe Min: 56
Collector- Emitter Voltage VCEO Max: 50 V
